ISUZU 5tons Tow Truck

Flatbed Tow Truck ISUZU
5tons Tow Truck




  • Flatbed tow truck (also called tow truck, road wrecker truck, recovery truck, breakdown lorry, wrecker, police rescue truck, wrecker tow truck, boom truck, wheel-lift wrecker ) is used to transport motor vehicles or the vehicles that are broken down.

Based on the type or size of vehicle to be towed, wreckers are usually designed into two types. One is slidebed tow truck with wheel-lift function; another one is wheel-lift units that offer a combination boom with sling.
Features:
---- ISUZU chassis, perfect performance.
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure
---- High quality hydraulic system
---- Massive, durable, perfect performance
---- Prolonged service life
Specification:
Similar Key Words:  ISUZU road wrecker, tow truck, police rescue truck, breakdown truck, recovery truck, flatbed tow truck, boom truck, wheel-lift wrecker, heavy recovery vehicle
Flatbed Tow Truck ISUZU ( 5 tons)
GeneralVehicle BrandSPV
Chassis BrandISUZU
Overall Dimension8485 x 2420 x 2500 mm
GVW / Kerb Weight10,000 kg / 5,675kg
CabCab Capacity3 persons allowed
Air ConditionerAir conditioner equipped
EngineFuel TypeDiesel
Engine BrandISUZU engine, 4HK1-TCG40
Power189 HP (139 KW)
Displacement5193 ml
Emission StandardEuro IV
ChassisDrive Type4X2, left hand drive
Transmission6 forward gears and 1 revers
Wheelbase/No. of axle4475 mm / 3
Tyre Specification235/75R17.5-14PR, 8.25-20-14PR, 8.25R20-14
Tyre Number6 tyres and 1 spare tyre
Max Speed95 km/h
PaintMetallic paint
SuperstructureTowing TypeSlide bed with wheel – lift
Flatbed Payload5 tons
Towing Capacity3.6 tons
Hydraulic WinchOne 40KN hydraulic winch with 25m galvanised wire rope connect one hook
All other standard accessories: 3 working lights, one tool box and hand washing tank, one set L-type tires holder,6pcs bundling belt and one LED alarm light etc.
OptionalCrane could be installed on flatbed wrecker.


Photo 1: Front view of ISUZU Flatbed Tow Truck


Photo 2: Left side view of ISUZU Flatbed Tow Truck


Photo 3: Left back view of ISUZU Flatbed Tow Truck
