Dongfeng 6,000 Litres LPG Dispensing Tanker

LPG Dispenser Truck Dongfeng
6,000 Litres LPG Dispensing Tanker
LPG Dispenser Truck Dongfeng

Function:
LPG dispenser truck (also called LPG dispensing tanker, LPG tanker truck, LPG tank truck, LPG delivery truck, LPG truck mounted transport tank, LPG truck tank, LPG road tanker truck) is used to transport liquefied petroleum gas, such as propane, liquid ammonia, dimethyl ether (DME), isobutene, etc.

LPG transport tank truck also can be used as a mobile gas station after equipped with gas dispenser, LPG gas pump.

The LPG tanker material uses a specialized steel for high pressure tanker, which is anti-corrosive and keeps a good stability at low or high temperature.

LPG tanker trucks are basically equipped with safety valve, emergency shut-off valve, thermometer, pressure gauge for the safety use.
Features:
---- Dongfeng chassis, perfect performance
---- Cummins engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure
---- Strong, durable, perfect performance
---- Prolonged service life
Specification:

LPG Dispenser Truck Dongfeng (6,000 Litres )
GeneralVehicle BrandSPV
Chassis BrandDongfeng
Overall Dimension7400 * 2300 * 2800 mm
GVW / Kerb Weight8,800 kg / 4,500 kg
CabCab Capacity2 persons allowed
Air ConditionerAir conditioner is optional
EngineFuel TypeDiesel
Engine BrandCUMMINS engine
Power140 Hp (103 KW)
Displacement4500 ml
Emission StandardEuro III
ChassisDrive Type4X2, left hand or right hand drive
Transmission5-speed forward, 1-reverse
Wheelbase/No. of axle3800 mm / 2
Tyre Specification8.25-16
Tyre Number6 tyres and 1 spare tyre
Max Speed110 km/h
PaintMetallic paint
SuperstructureTank Capacity6,000 Litres
Tank MaterialSpecialized steel for high pressure gas tank
Tank Thickness10 mm
Designe Pressure1.77 Mpa
Designe Temperature50 °C
LPG DispenserEquipped, with ticket printer
All other standard accessories: inlet/outlet, safety valve, emergency shut-off valve, drainback system, thermometer, pressure gauge, fire extinguisher, anti-static grounding tape…
Optional** Separate inlet and outlet.
** Pump, gas dispenser….

LPG Dispenser Truck Dongfeng - F
Photo 1: Left Front View of LPG Dispenser Truck Dongfeng

LPG Dispenser Truck Dongfeng - LB
Photo 2: Left Back View of LPG Dispenser Truck Dongfeng

LPG Dispenser Truck Dongfeng - RF
Photo 3: Right Front View of LPG Dispenser Truck Dongfeng

LPG Dispenser Truck Dongfeng - RS
Photo 4: Right Side View of LPG Dispenser Truck Dongfeng

LPG Dispenser Truck Dongfeng - RB
Photo 5: Right Back View of LPG Dispenser Truck Dongfeng

LPG Dispenser Truck Dongfeng - Details
Photo 6: Details of LPG Dispenser Truck Dongfeng
Similar Key Words: truck mounted LPG tanker, LPG tanker truck, LPG tank truck, LPG delivery truck, LPG truck mounted transport tank, LPG truck tank, LPG road tanker truck
