ISUZU 10 m³ Water Tank and 2m³ Foam Tank

Fire Fighting Truck ISUZU

10 m³ Water Tank and 2m³ Foam Tank

•
•
•

Function:

Fire fighting truck (also called foam fire tanker, fire engine, fire apparatus, water foam truck, foam fire truck, foam fire tank truck, fire hydrant and fire water tanker, fire service truck) is a vehicle designed primarily for fire fighting operations - to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximumly.

Fire fighting truck can be divided into many types:

1. According to vehicle size, there are mini fire fighting truck, light fire fighting truck, medium fire fighting truck, heavy-duty fire fighting truck.
2. According to chassis drive type, there are 4X2 fire fighting truck, 6X4 fire fighting truck, 8X4 fire fighting truck, and off-road type 4X4, 6X6 fire fighting truck.
3. According to chassis brand, there are ISUZU fire fighting truck, Dongfeng fire fighting truck,  Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Mercedes fire fighting truck, etc.
4. According to fire agent,  there are water tank fire fighting truck, dry powder fire fighting truck, water/foam fire fighting truck.

Features:

---- ISUZU chassis, perfect performance.
---- ISUZU engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure.
---- High quality fire pump.
---- Massive, durable, long service life.
---- 12,000 Litres fire truck carries 10,000 litres water tank and 2,000 litres foam tank

Specification:

Fire Fighting Truck ISUZU (12,000 litres)
General	Vehicle Brand	SPV
	Chassis Brand	ISUZU
	Overall Dimension	10150 * 2500 * 3500 mm
	GVW / Kerb Weight	24,500 kg / 12,050 kg
Cab	Cab Capacity	2+4 persons allowed
	Air Conditioner	W/ air conditioner
Engine	Fuel Type	Diesel
	Engine Brand	ISUZU engine, 6HK1
	Power	280 Ps (206 KW)
	Displacement	7790 ml
	Emission Standard	Euro IV
Chassis	Drive Type	6X4, left hand drive
	Transmission	ISUZU gear box, no overhaul within 500,000km
	Wheelbase/No. of axle	5100+1300 mm / 3
	Tyre Specification	11.00-20
	Tyre Number	10 tyres and 1 spare tyre
	Max Speed	90 km/h
	Paint	Metallic paint
Superstructure	Water Capacity	10,000 Litres ( About 2,600 gallons)
	Foam Capacity	2,000 Litres (About 500 gallons)
	Tank Material	Carbon steel
	Fire Pump	Flow speed	60 L/s
		Pressure	1.0M Pa
	Fire Cannon	Flow speed	48 L/s
		Shot	Water	≥ 60 m
			foam	≥ 55 m
	Suction Head	6 m
	Hose	High quality, wire strengthened hose, with cooper wire, anti-static
	All standard accessories: Typical modern fire apparatus carries equipment for a wide range of firefighting and rescue tasks. These include  shovel, pike poles, axes and cutting equipment, halligan bars.…
Optional	Ladders, floodlights…
