Sinotruk 5 m³ Water Tank and 2m³ Foam Tank

Fire Apparatus Sinotruk

5 m³ Water Tank and 2m³ Foam Tank

•
•

Function:

Fire apparatus (also called fire engine, fire fighting truck, water foam tanker, foam fire truck, fire-extinguisher foam tanker, fire appliance, fire service truck, fire fighting foam truck) is a vehicle designed primarily for fire fighting operations - to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximumly.

Fire fighting truck can be divided into many types:

1. According to vehicle size, there are mini fire fighting truck, light fire fighting truck, medium fire fighting truck, heavy-duty fire fighting truck.
2. According to chassis drive type, there are 4X2 fire fighting truck, 6X4 fire fighting truck, 8X4 fire fighting truck, and off-road type 4X4, 6X6 fire fighting truck.
3. According to chassis brand, there are ISUZU fire fighting truck, Dongfeng fire fighting truck,  Foton fire fighting truck, FAW fight fighting truck, Shacman fire fighting truck, sinotruk fire fighting truck, Mercedes fire fighting truck, etc.
4. According to fire agent,  there are water tank fire fighting truck, dry powder fire fighting truck, water/foam fire fighting truck.

Features:

---- Sniotruk chassis, perfect performance.
---- Sinotruk engine, super powerful; reliable performance, no overhaul within 100,000 km.
---- Nice shape, rational structure.
---- High quality fire pump.
---- Massive, durable, long service life.
---- 7,000 Litres fire truck carries 5,000 litres water tank and 2,000 litres foam tank

Specification:

Fire Apparatus Sinotruk (7,000 Litres)
General	Vehicle Brand	SPV
	Chassis Brand	Sinotruk
	Overall Dimension	8900 * 2500 * 3600 mm
	GVW / Kerb Weight	18,900kg / 10,640kg
Cab	Cab Capacity	2+4 persons allowed
	Air Conditioner	Air conditioner is optional
Engine	Fuel Type	Diesel
	Engine Brand	Sinotruk
	Power	270 Ps (198 KW)
	Displacement	9726 ml
	Emission Standard	Euro III
Chassis	Drive Type	4X2, left hand or right drive
	Transmission	10-speed front, 1 reverse
	Wheelbase/No. of axle	4500 mm / 2
	Tyre Specification	10.00-20
	Tyre Number	6 tyres and 1 spare tyre
	Max Speed	90 km/h
	Paint	Metallic paint
Superstructure	Water Capacity	5,000 Litres (About 1,300 gallons)
	Foam Capacity	2,000 Litres (About 500 gallons)
	Tank Material	Carbon steel
	Fire Pump	Flow speed	60L/s
		Pressure	1.0MPa
	Fire Cannon	Flow speed	Water	48 L/s
			Foam	48 L/s
		Shot	Water	60 m
			Foam	55 m
	Suction Head	6 m
	Hose	High quality, wire strengthened hose, with cooper wire, anti-static
	All standard accessories: Typical modern fire apparatus carries equipment for a wide range of firefighting and rescue tasks. These include  shovel, pike poles, axes and cutting equipment, halligan bars.…
Optional	Ladders, floodlights...
